1x6 SC G657A2 0.9mm white cable 1meter mini model PLC splitter
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | Takfly/OEM |
| Certification: | CE, ISO, RoHS, CPR, FCC |
| Model Number: | SC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50 pcs |
|---|---|
| Price: | Can be negotiated |
| Packaging Details: | standard export packing |
| Delivery Time: | 3-15 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, Paypal |
| Supply Ability: | 100000 pcs/ Month |
|
Detail Information |
|||
| Product Name: | 1x6 SC G657A2 0.9mm White Cable 1meter Mini Model PLC Splitter | Connector: | SC APC |
|---|---|---|---|
| Mode: | SM G657A2 | Cable Diameter: | 0.9mm |
| Cable Color: | White | Packing: | Mini Tube |
| Length: | Input 1M; Output 1M | Operating Wavelength(nm): | 1260 ~ 1650 |
| Type: | 1*6 | Max.Insertion Loss（dB）: | 10.3 |
| Max.Uniformity（dB）: | 0.8 | Min.Return Loss（dB: | 55 |
| Max.PDL（dB）: | 0.3 | Fiber Type: | ITU-T G657A1 , G657A2 And G.652D |
| Max.Temperature Stability （dB）: | 0.5( Typical 0.3 ) | Operating Temperature（℃: | -40 ~ +85 |
| Storage Temperature（℃）: | -40 ~ +85 | ||
Product Description
Fiber Optic PLC Splitter Product Name:
1x6 SC G657A2 0.9mm white cable 1meter mini model PLC splitter
Fiber Optic PLC Splitter introduction:
PLC splitter advantage:
1, the loss is not sensitive to the transmission of optical wavelength, can meet the transmission needs of different wavelengths (1260-1650nm).
2, evenly divided, the signal can be evenly distributed to the user.
3, small size (e.g. 1×32 minimum size can be done (4×7×50mm), can be installed directly in the existing various transfer boxes, without special design to allow a large installation space.
4, a single device diversion channel a lot, can reach more than 32.
5, low cost of multiple ways, the more the number of divisions, the more obvious the cost advantage.
Fiber Optic PLC Splitter package type: bare fiber type, rack-mount type, modular type, Fanout type, 24-core tray type, 1u tray type, large steel pipe 900um, 12 core tray type, outdoor fiber box type.
Fiber Optic PLC Splitter Feature:
- Broadband Operation Wavelength
- Low Insertion loss
- Low PDL
- Compact Design
- Good channel-to-channel uniformity
- High Reliability and Stability
Fiber Optic PLC Splitter Application:
- Telecommunication sector
- PON System
- FTTH
- CATV
- Video Transmission
Fiber Optic PLC Splitter Parameter:
1×N PLC Splitter
(Measured at room temperature and excludes connector loss)
| Type | 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | ||
| Fiber Type | ITU-T G657A1 , G657A2 and G.652D | ||||||
| Operating Wavelength (nm) | 1260~1650 | ||||||
| Insertion Loss (dB) | Typical | 3.6 | 6.8 | 10.0 | 13.0 | 16.0 | |
| (P/S) Max | 3.8/4.0 | 7.1/7.3 | 10.2/10.5 | 13.5/13.7 | 16.5/16.8 | ||
| Loss Uniformity (dB) | Max | 0.6 | 0.6 | 0.8 | 1.2 | 1.5 | |
| Polarization Dependent Loss (dB) | Max | 0.15 | 0.15 | 0.25 | 0.3 | 0.3 | |
| Directivity (dB) | Min | 55 | |||||
| Return Loss (dB) | Min | UPC:50 APC:55 | |||||
| Operating Temperature(℃) | -40~85 | ||||||
| Storage Temperature(℃) | -40~85 | ||||||
2×N PLC Splitter
(Measured at room temperature and excludes connector loss)
| Type | 2×2 | 2×4 | 2×8 | 2×16 | 2×32 | 2×64 | |
| Fiber Type | ITU-T G657A1 , G657A2 and G.652D | ||||||
| Operating Wavelength (nm) | 1260~1650 | ||||||
| Insertion Loss (dB) | Typical | 4.0 | 7.0 | 10.5 | 13.5 | 16.5 | 20.5 |
| (P/S) Max | 4.1/4.3 | 7.4/7.6 | 10.8/11.0 | 14.3/14.5 | 17.3/17.5 | 20.7/21.5 | |
| Loss Uniformity (dB) | Max | 0.8 | 0.8 | 1.5 | 2.0 | 2.5 | 2.5 |
| Polarization Dependent Loss (dB) | Max | 0.2 | 0.2 | 0.3 | 0.4 | 0.4 | 0.4 |
| Directivity (dB) | Min | 55 | |||||
| Return Loss (dB) | Min | UPC:50 APC:55 | |||||
| Operating Temperature(℃) | -40~85 | ||||||
| Storage Temperature(℃) | -40~85 | ||||||
Package Dimensions
| Port | 1x2 | 2x2 | 1x4 | 2x4 | 1x8 | 2x8 | 1x16 | 2x16 | 1x32 | 2x32 | 1x64 | 2x64 |
How to order Fiber Optic PLC Splitter:
1. Connector type : SC / FC / LC / ST/ E2000
2. Mode type : single mode UPC and APC
3. Cable diameter : 0.9 / 2.0 / 3.0 mm
4. Packing type : mini steel tupe / ABS box
5. fiber count : 1xN, 2xN(1x2,1x4, 2x2, 2x4,etc)
