FTTH Indoor Multi-Purpose Distribution Cable GJPFJH-4X | Telecommunications Solution & Data Center
Product Details:
| Place of Origin: | China, Shenzhen |
| Brand Name: | DF/OEM/Nuetral |
| Certification: | CE/ROHS/REACH/ISO9001/ISO14001 |
| Model Number: | FTTH Indoor Multi-Purpose Distribution Cable GJPFJH-4X | Telecommunications Solution & Data Center |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiable |
|---|---|
| Price: | negotiable denpend on QTY |
| Packaging Details: | Blister box+Carton |
| Delivery Time: | 5-9 working days depends on QTY |
| Payment Terms: | Western Union,T/T,/Paypal |
| Supply Ability: | 1000PCS/Day |
|
Detail Information |
|||
| Product Name: | FTTH Indoor Multi-Purpose Distribution Cable GJPFJH-4X | Telecommunications Solution & Data Center | Fiber Count: | 4 |
|---|---|---|---|
| Core Reinforce: | Aramid Yarn | Material: | Stainless Steel |
| Jacket Material: | LSZH/PVC | Color: | Natural Color Or Customized |
| Wavelength: | 1310nm, 1550nm | Diameter(±1µm): | 125μm |
| Tense Strength: | 100-200 N | Coating Diameter(±5µm): | 250μm |
| Operation Temperature: | -20℃~60℃ | Length: | 2000M Or Customized |
| Fiber Brand: | Corning, YOFC, OFS, Draka | ||
| Highlight: | FTTH indoor distribution cable,GJPFJH-4X fiber optic cable,multi-purpose fiber optic cable |
||
Product Description
The GJPFJH-4X is a 4-core indoor multi-purpose distribution cable engineered for FTTH, telecommunications, and data center deployments. It combines a 900µm compact buffer fiber subunit, aramid yarn reinforcement, and a central fiber-reinforced plastic (FRP) strength member within a 5.0 mm inner sheath, finished with a PVC or LSZH flame-retardant outer jacket.
Four 900µm compact buffer fibers are grouped as a subunit, reinforced with aramid yarn and enclosed in a 5.0 mm inner sheath. A non-metal fiber-reinforced plastic (FRP) rod sits at the center of the core as the strengthening member, with the subunit laid around it. The cable is completed with a PVC or low-smoke halogen-free (LSZH) outer jacket offering flame retardancy and low smoke emission.
- Optical fiber active connection jumpers and pigtails
- Indoor shaft and forced-ventilation level cabling
- Interconnection of instruments and communication equipment
- Tight-buffered optical fiber for easy stripping and termination
- Aramid yarn reinforcement delivers excellent tensile resistance
- Multi-core design with a small outer diameter and non-metal central strength structure
- Flame-retardant performance with low induced attenuation across the operating temperature range
- Configurable to meet diverse market and customer requirements
- More than 25 years of manufacturing experience in fiber optic products
- Over 450 assembly workers with 3+ years of experience
- More than 10 R&D engineers
- 16 German-imported injection machines and 16 production lines
- 30+ testing machines including OTDR, 3D, VFL, IL&RL test instruments, tensile strength tester, crush resistance tester, power meter, and light checker
- OEM branding accepted
- Exhibitions: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia, Global Sources Electronic Exhibition, and more
- Spot-check incoming raw materials before production
- Full inspection after every individual process
- Full inspection at production midpoint
- Full inspection of finished products before packing
- Spot-check before shipping
- Samples: 1–3 working days
- Mass production orders: 3–7 working days
- Packaging: plastic bag, carton, and pallet options available on request
If you are interested in our products or have any questions, feel free to contact us at any time.
