RoHS Compliant 100Gb/s CFP2 1310nm 10km Optical Receiver | High Quality and Fiber Optical Network | OLCFxxTXL-CD10R
Product Details:
| Place of Origin: | China, Shenzhen |
| Brand Name: | DF/OEM/Nuetral |
| Certification: | CE/ROHS/REACH/ISO9001/ISO14001 |
| Model Number: | RoHS Compliant 100Gb/s CFP2 1310nm 10km Optical Receiver | High Quality and Fiber Optical Network | OLCFxxTXL-CD10R |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiable |
|---|---|
| Price: | negotiable denpend on QTY |
| Packaging Details: | Blister box+Carton |
| Delivery Time: | 5-9 working days depends on QTY |
| Payment Terms: | T/T,/Paypal,L/C |
| Supply Ability: | 1000PCS/Day |
|
Detail Information |
|||
| Product Name: | RoHS Compliant 100Gb/s CFP2 1310nm 10km Optical Receiver | High Quality And Fiber Optical Network | OLCFxxTXL-CD10R | Supply Voltage: | 3.14-3.46V |
|---|---|---|---|
| Supply Current: | 300 MA | Input Differential Impedance: | 100 Ω |
| Single Ended Data Input Swing: | 180-700 MA | Data Input Swing Differentia: | 400-1800 MV |
| Transmit Disable Assert Time: | 10 Us | Differential Data Output Swing: | 300-850 MA |
| Operating Case Temperature: | 0 To +70°C | Warranty: | 1 Years, Lifetime Maintenance |
| Fiber Brand: | Corning, YOFC, OFS, Draka | ||
| Highlight: | RoHS compliant CFP2 optical receiver,100Gb/s fiber optic network,1310nm 10km optical transceiver |
||
Product Description
RoHS Compliant 100Gb/s CFP2 1310nm 10km Optical Receiver
High Quality Fiber Optical Network | Model: OLCFxxTXL-CD10R
Product Overview
High performance 100G CFP2 Optical Receiver solution supporting 100G Ethernet, InfiniBand, fiber channel, PCIe, and SAS applications. This high-quality receiver provides reliable connectivity for demanding data center environments.
Applications
- Local Area Network (LAN)
- Wide Area Network (WAN)
- Switch to router interface
- ITU-T OTU4 OTL4.4 applications
Key Features
Duplex LC receptacle optical interface
Single +3.3V power supply
Hot-pluggable design
Operating optical data rate up to 112Gbps
Operating electrical serial data rate up to 27.952493Gbps
4 parallel electrical serial interface
AC coupling of CML signals
APD (ROSA) technology
Low power dissipation (Max: 6W)
Built-in digital diagnostic function
Operating case temperature range: 0℃ to 70℃
Compliant with 100GBASE-LR4 and OTU4
MDIO Communication Interface
Compatible with all kinds of commercial ONT
Compliance Standards
- Compliant with IEEE 802.3ba
- Compliant with CFP2 MSA hardware specifications
- Compliant with CFP2 MSA management specifications
- Compliant with ITU-T G709/Y.1331
- Compliant with RoHS
Technical Documentation
Product Images
Why Choose TAKFLY?
26+ years of manufacturing experience in fiber optic products
450+ assembly workers with 3+ years of experience
10+ R&D Engineers dedicated to innovation
16 Germany-imported Injection Machines and production lines
30+ testing machines including OTDR, 3D, VFL, IL&RL test instruments
Comprehensive testing equipment: tension strength testers, crush resistance testers, power meter testers, light checkers
OEM branding accepted
Global exhibition participation: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia, Global Source Electronic Exhibition
Quality Control Process
- Raw material spot checking before production
- Full inspection after every individual process
- Comprehensive half-done production checks
- Complete finished product inspection before packing
- Pre-shipping spot checks
Delivery Information
- Samples: 1-3 working days
- Mass Production Orders: 3-7 working days
- Packaging: Plastic bags, cartons, and pallets available per request
Frequently Asked Questions
How can I get your catalogue and price list?
Please provide your email or contact information through our website to receive our catalogue and price list.
Can I negotiate the prices?
Yes, we may consider discounts for multiple container loads of mixed goods.
How much will the shipping charges be?
Shipping charges depend on your shipment size and shipping method. We will provide charges upon request.
Can I visit you?
Certainly! Our factory is located in Shenzhen, China. Please contact us to schedule an appointment.
What if there is quality problem when we get the goods?
If you encounter quality issues upon unpacking, please take photos for our reference. Our QC department will investigate and provide the best solutions, along with implementing quality improvements for future production.
What is your terms of packing?
We typically pack goods in blister boxes and cartons, but can accommodate custom packaging requests from customers.
What is your terms of payment?
T/T 30% as deposit, and 70% balance before delivery. We provide photos of products and packaging before final payment.
What is your terms of delivery?
EXW, FOB, CFR, CIF, DDU
How about your delivery time?
Generally 5-7 working days after receiving advance payment. Specific delivery time depends on items and order quantity.
Can you produce according to the samples?
Yes, we can manufacture products based on your samples or technical drawings.
