SC-LC Duplex OM3 Fiber Optic Patch Cord 2.0mm 100N Tensile
Product Details:
| Certification: | RoHS, CE, ISO9001, VDE, CCC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 2.2 |
|
Detail Information |
|||
| Connection Structure: | SC | Material Shape: | Round Wire |
|---|---|---|---|
| Allowed Lateral Pressure: | 100(N/100mm) | Allowed Tensile Strength: | 100N<1000N |
| Core: | Simplex Duplex Quard | Sheath Material: | PVC, LSZH |
| Cable Length: | 1m.3m.5m Or Customized | Operating Temperature: | -40c~+80c |
| Fiber Mode: | Single Mode Or Multi-Mode | Cable Diameter: | 0.9mm,2.0mm,3.0mm |
| Operation Wavelength: | 1310/1550nm | Insertion Loss: | ≤0.3dB |
| Return Loss: | ≥45dB | Exchangeability: | ≤0.2dB |
| Vibration: | ≤0.2dB | ||
| Highlight: | SC-LC OM3 fiber optic patch cord,duplex fiber optic cable 2.0mm,OM3 patch cord with 100N tensile |
||
Product Description
SC-LC Duplex OM3 Fiber Optic Patch-Cord
Product Description
The SC-LC Duplex OM3 Fiber Optic Patch Cord is a high-performance cable designed for connecting devices in signal routing applications. This patch cord features FC (Fixed Connection) connectors with threaded barrel housing, constructed with nickel-plated metal housing for durability.
Key Features
- Low insertion loss and high return loss
- Excellent mechanical endurance
- High credibility and stability
- Superior repeatability and exchangeability
Applications
- Testing equipment
- FTTX+LAN networks
- Optical fiber CATV systems
- Optical communication systems
- Telecommunication infrastructure
Technical Specifications
| Parameter | Unit | FC, SC, LC/ Armoured | ST, MU | MT-RJ, MPO | E2000 |
|---|---|---|---|---|---|
| Insertion loss (typical) | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 |
| Return loss | dB | ≥45 | ≥50 | ≥60 | ≥30 |
| Operating wavelength | nm | 1310, 1510 | 1310, 1510 | ||
| Exchangeability | dB | ≤0.2 | ≤0.2 | ||
| Vibration | dB | ≤0.2 | ≤0.2 | ||
| Operating temperature | °C | -40~75 | -40~75 | ||
| Storage temperature | °C | -45~85 | -45~85 | ||
| Cable diameter | mm | φ3.0, φ2.0, φ0.9 | φ3.0, φ2.0, φ0.9 |
Why Choose Takfly Communications Co., Ltd?
TAKFLY specializes in fiber optic solutions including patch cords, connectors, adapters, and various optical components for telecommunications, broadband, broadcast, CATV, and network industries.
- Fast delivery and competitive pricing
- Professional product and technical support
- Prompt response to inquiries
- Reliable quality with OEM services available
- Long-term warranty
- Value-added services including logistics support
For any questions or inquiries about this product, please feel free to contact us. We welcome your business and look forward to serving you.
