Customized Fiber Optic Patch Cable 0.9mm-3.0mm 1m-10m Length
Product Summary
Customized Fiber Optic Patch Cable Our customized Fiber Optic Patch Cables are available in various lengths (1.1m, 3m, 5m, 10m) with 2.0mm or 3.0mm loose tube options and UPC or APC end face configurations. Ideal for equipment jumper cables, cross connects, and work area connections. All patch cords ...
Product Custom Attributes
Model NO.:
TK-9004
Material Shape:
Round Wire
Allowed Lateral Pressure:
>1000(N/100mm)
Allowed Tensile Strength:
1000N<10000N
Core:
Single Or Multi Core
Sheath Material:
PVC
Fiber Type:
0.9mm 2.0mm 3.0mm
Fiber Length:
1m 3m 5m 10m Or Customized
Insertion Loss:
<0.3dB
Return Loss:
≥50dB
Repeatability:
≤0.1
Durability:
<0.1dB Typical Change,1000 Mating
Interchangeability:
≤0.2dB
Operating Temperature:
-20°C ~ +70°C
Storage Temperature:
-40°C ~ +80°C
Highlight:
customized fiber optic patch cable
,fiber optic cable 0.9mm-3.0mm
,fiber optic patch cable 1m-10m
Basic Properties
Certification:
RoHS, CE
Trading Properties
Minimum Order Quantity:
1
Price:
1.2
Product Description
Customized Fiber Optic Patch Cable
Our customized Fiber Optic Patch Cables are available in various lengths (1.1m, 3m, 5m, 10m) with 2.0mm or 3.0mm loose tube options and UPC or APC end face configurations.
Ideal for equipment jumper cables, cross connects, and work area connections. All patch cords are manufactured using OFNR riser grade cable and are 100% factory tested to ensure performance to TIA/EIA-568-B-3 standards.
Available Configurations
- ST/ST, SC/SC, FC/FC, LC/LC and hybrid ST/SC connectors
- Multimode (62.5/125µ M and 50/125µ M) and single mode cable types
- Duplex and simplex versions available
Key Features
- Excellent durability and exchangeability
- High temperature stability
- Low insertion loss and back reflection loss
- Superior Quality Standard PC/UPC/APC Polishing
- Compliant with Telcordia GR-326-CORE, TIA/EIA and IEC standards
- RoHS compliant green production
- High stability in various environments
- Custom orders available
Technical Specifications
| Descriptions | SM(PC) | SM(UPC) | SM(APC) | MM(PC) |
|---|---|---|---|---|
| Insertion loss | <0.3dB | ≤0.2dB | <0.3dB | <0.3dB |
| Return loss | ≥50dB | ≥50dB | ≥65dB | ≥35dB |
| Repeatability | ≤0.1 | ≤0.1 | ≤0.1 | ≤0.1 |
| Durability | <0.1dB typical change, 1000 mating | |||
| Interchangeability | ≤0.2dB | |||
| Vibration | ≤0.2dB | |||
| Operating Temperature | -20°C ~ +70°C | |||
| Storage Temperature | -40°C ~ +80°C | |||
| Cable Diameter | 3.0mm, 2.0mm, 0.9mm | |||
