HDMI 2.0 Fiber Optic Extender
Product Details:
| Place of Origin: | China, Shenzhen |
| Brand Name: | DF/OEM/Nuetral |
| Certification: | CE/ROHS/REACH/ISO9001/ISO14001 |
| Model Number: | HDMI 2.0 Fiber Optic Extender |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiable |
|---|---|
| Price: | negotiable denpend on QTY |
| Packaging Details: | Blister box+Carton |
| Delivery Time: | 5-9 working days depends on QTY |
| Payment Terms: | Western Union, T/T, MoneyGram/Paypal |
| Supply Ability: | 1000PCS/Day |
|
Detail Information |
|||
| Product Name: | HDMI 2.0 Fiber Optic Extender | Standards: | HDMI 2.0; HDCP 2.2 |
|---|---|---|---|
| Interface: | SFP Model – LC Connector | Fiber Type: | Single-mode |
| Wavelength: | T-1310nm R-1550nm | Interface Bandwidth: | 2.5Gbps |
| Data Bits: | 8 | Power Supply: | The Power Adapter: DC 12V |
| Operating Temperature: | -5℃ ~ +70℃ | Humidity: | 5% ~ 90% |
| Dimension: | 123*82*23mm | Warranty: | 1 Years, Lifetime Maintenance |
| Fiber Brand: | Corning, YOFC, OFS, Draka | ||
| Highlight: | HDMI 2.0 fiber optic extender,fiber optic termination box with warranty,HDMI extender for long-distance transmission |
||
Product Description
HDMI 2.0 Fiber Optic Extender
Product Overview
The HDMI Fiber Optic Extender provides extension of HDMI signals over long distances using a single fiber optic cable. It supports high resolution up to 3840×2160@60Hz and is suitable for a wide range of applications requiring long-distance transmission of high-resolution content with excellent stability and security.
Key Features
- Transmits HDMI video signals up to 1-20km over a pair of fiber optic cables
- Supports video resolution up to 3840×2160@60Hz
- Supports screen formats YUV444 and RGB444
- Compliant with HDMI 2.0 and HDCP 2.2 standards
- Supports RS232 two-way transmission
- Supports USB keyboard and mouse
- Supports embedded audio input and output
- Supports bidirectional transmission of infrared signals
- High compatibility with automatic source and display device matching
- Built-in automatic adjustment system for smooth, clear, and stable images
- Simple plug-and-play installation
Technical Specifications
| Parameter | Description |
|---|---|
| Video Standards | HDMI 2.0; HDCP 2.2 |
| Maximum Pixel Clock | 340MHz |
| Maximum Data Rate | 18Gbps |
| Maximum Resolution | 3840×2160@60Hz |
| Connector | HDMI-A |
| Impedance | 100Ω |
| Optical Fiber Interface | SFP model - LC connector |
| Fiber Type | Single-mode |
| Wavelength | T-1310nm R-1550nm |
| Interface Bandwidth | 2.5Gbps |
| IR Interface | 3.5mm earphone seat |
| IR Frequency | 28Khz-61Khz |
| RS232 Interface | Industrial Terminal |
| Signal Direction | Duplexing |
| Baud Rate | Self-adaptive Max: 115200bps |
| Data Bits | 8 |
| Power Supply | DC 12V power adapter |
| Power Dissipation | MAX 13W |
| Operating Temperature | -5℃ ~ +70℃ |
| Operating Humidity | 5% ~ 90% |
| Dimension | 123×82×23mm |
| Warranty | 1 year free warranty |
Panel Layout
Transmitter
Receiver
| Port Name | Description |
|---|---|
| IR IN/OUT | IR Input/Output |
| HD IN/HD OUT | HDMI Input/Output |
| UTP | RJ45 cable port |
| USB | USB Host for console or laptop connection |
| K/M | Keyboard/mouse |
| T/G/R | RS232 interface with TXD/GND/RXD at the terminal |
| DC12V | Power input |
| LED Indicator | Description |
|---|---|
| FIBER | Detects the SFP fiber module |
| LINK | Normal state: off; Flashing once: NO Link; Flashing three times: forward video normal, reverse data abnormal; Flashing four times: forward video abnormal, reverse data normal |
| STA | Light always on when in normal condition |
| PWR | Power indicator |
Product Images
Why Choose TAKFLY
- 26+ years of manufacturing experience in fiber optic products
- 450+ assembly workers with 3+ years of experience
- 10+ R&D Engineers dedicated to innovation
- 16 Germany-imported Injection Machines and production lines
- 30+ testing machines including OTDR, 3D, VFL, IL&RL test instruments
- Comprehensive testing equipment: tension strength testers, crush resistance testers, power meter testers, light checkers
- OEM branding accepted
- Global exhibition participation: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia, Global Source Electronic Exhibition
Quality Control
- Raw material spot checking before production
- Full inspection after every individual process
- Comprehensive half-done production checks
- Complete finished product inspection before packing
- Pre-shipping spot checks
Delivery Information
- Samples: 1-3 working days
- Mass Production Orders: 3-7 working days
- Packaging: Plastic bags, cartons, and pallets available per request
Frequently Asked Questions
Q1: How can I get your catalogue and price list?
Please provide your email or contact information through our website to receive our catalogue and price list.
Q2: Can I negotiate the prices?
Yes, we may consider discounts for multiple container loads of mixed goods.
Q3: How much will the shipping charges be?
Shipping charges depend on your shipment size and shipping method. We will provide charges upon request.
Q4: Can I visit you?
Certainly! Our factory is located in Shenzhen, China. Please contact us to schedule an appointment.
Q5: What if there is quality problem when we get the goods?
If you encounter quality issues upon unpacking, please take photos for our reference. Our QC department will investigate and provide the best solutions, along with implementing quality improvements for future production.
Q6: What is your terms of packing?
We typically pack goods in blister boxes and cartons, but can accommodate custom packaging requests from customers.
Q7: What is your terms of payment?
T/T 30% as deposit, and 70% balance before delivery. We provide photos of products and packaging before final payment.
Q8: What is your terms of delivery?
EXW, FOB, CFR, CIF, DDU
Q9: How about your delivery time?
Generally 5-7 working days after receiving advance payment. Specific delivery time depends on items and order quantity.
Q10: Can you produce according to the samples?
Yes, we can manufacture products based on your samples or technical drawings.
If you're interested in our products or have any questions, feel free to contact us at any time!
