• TK-1392-3LCD2 10Gbps 1310nm 2KM SFP+ Optical Transceiver Applicable For 2km SMF Connection
TK-1392-3LCD2 10Gbps 1310nm 2KM SFP+ Optical Transceiver Applicable For 2km SMF Connection

TK-1392-3LCD2 10Gbps 1310nm 2KM SFP+ Optical Transceiver Applicable For 2km SMF Connection

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Takfly
Certification: CE,ROHS,FCC,REACH,ISO9001,ISO14001
Model Number: TK-1392-3LCD2

Payment & Shipping Terms:

Minimum Order Quantity: 10 pcs
Price: Can be negotiated
Packaging Details: blister box + spone + carton
Delivery Time: 3-5 working days
Payment Terms: T/T, Western Union, MoneyGram, Paypal, L/C
Supply Ability: 3000pcs/month
Get Best Price Contact Now

Detail Information

Speed: 10Gbps Transmission Distance: 2KM
Compatible Switch Brand: CISCO/HP/Huawei/H3C/Juniper/ZTE/........ Wavelength: Tx1270/1330nm / Rx1330/1270nm
Fiber Port: LC Fiber Type: SM
Highlight:

2KM SFP+ Optical Transceiver

,

10Gbps SFP+ Optical Transceiver

,

1310nm SFP+ Optical Transceiver

Product Description



Description

     This 1310 nm DFB 10Gbps SFP+ transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 2KM.

    The SFP+ 2KM module electrical interface is compliant to SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential. Data lines are internally AC coupled. The module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI. SFI typically operates over 200 mm of improved FR4 material or up to about 150mm of standard FR4 with one connector.



Features

     Optical interface compliant to IEEE 802.3ae 10GBASE-LR

     Electrical interface compliant to SFF-8431

     Hot Pluggable

     1310nm FP transmitter, PIN photo-detector

     Operating case temperature: 0 to 70 °C

     Low power consumption

     Applicable for 2km SMF connection

     All-metal housing for superior EMI performance

     Advanced firmware allow customer system encryption information to be stored in transceiver

     Cost effective SFP+ solution, enables higher port densities and greater bandwidth

     RoHS6 compliant (lead free)



Applications



 10GBASE-LR at 10.3125Gbps

 Other optical links





Standard



 Compliant with SFF-8472 SFP+ MSA.

 Compliant to SFP+ SFF-8431 and SFF-8432.

 Compliant to 802.3ae 10GBASE-LR.

 RoHS Compliant.





Package Dimension


TK-1392-3LCD2 10Gbps 1310nm 2KM SFP+ Optical Transceiver Applicable For 2km SMF Connection 0




FAQ:

Q: Do you provide OEM service ?
A: Yes, we can print your logo or label on the products or on the box.



Q: Can you provide free samples ?
A: Some of low value samples can be free for you, but you need pay for the shipping cost.



Q: How can you guarentee the quality ?
A: Build on our perfect quality management system, all of our products were 100% tested before the shipment.



Q: What is your delivery time ?
A: Generally, sample: 3~5 working days. Formal order: 7-10 working days.



Q: What's your payment terms ?
A: We accept T/T, Western Union, Paypal, L/C
For samples: 100% payment. Formal order: 30%~100% as deposit, balance payment before shipment.
