• 40km Reach 1.25Gbps 1310nm SFP Optical Transceiver 40KM Transmission Distance
40km Reach 1.25Gbps 1310nm SFP Optical Transceiver 40KM Transmission Distance

40km Reach 1.25Gbps 1310nm SFP Optical Transceiver 40KM Transmission Distance

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Takfly
Certification: CE,ROHS,FCC,REACH,ISO9001,ISO14001
Model Number: TK-1324-3LCD40

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Can be negotiated
Packaging Details: blister box + spone + carton
Delivery Time: 3-5 working days
Payment Terms: T/T, Western Union, MoneyGram, Paypal, L/C
Supply Ability: 3000pcs/month
Get Best Price Contact Now

Detail Information

Speed: 1.25Gbps Transmission Distance: 40KM
Compatible Switch Brand: CISCO/HP/Huawei/H3C/Juniper/ZTE/........ Wavelength: 1310nm
Fiber Port: Duplex LC
Highlight:

1.25Gbps SFP Optical Transceiver

,

40km SFP Optical Transceiver

,

1310nm SFP Optical Transceiver

Product Description





Description

The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 40km-160km  transmission distance with SMF.
The transceiver consists of three sections: an uncooled CWDM DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.



Features



  • Dual data-rate of 1.25Gbps operation

  • 1550nm DFB laser and PIN photodetector for 40km/80km/120km160km transmission

  • Compliant with SFP MSA and SFF-8472 with duplex LC receptacle

  • Digital Diagnostic Monitoring:

  • Internal Calibration or External Calibration

  • Compatible with SONET OC-24-LR-1

  • Compatible with RoHS

  • +3.3V single power supply

  • Operating case temperature range:

    Standard : 0 to +70°C

    Extended : -20 to +85°C

    Industrial : -40 to +85°C



Applications



      Gigabit Ethernet.

      Fiber Channel.

      Switch to Switch interface.

      Switched backplane applications.

      Router/Server interface.

      Other optical transmission systems.





Absolute Maximum Ratings

40km Reach 1.25Gbps 1310nm SFP Optical Transceiver 40KM Transmission Distance 0





Optical and Electrical Characteristics
40km Reach 1.25Gbps 1310nm SFP Optical Transceiver 40KM Transmission Distance 1


Mechanical Dimensions


40km Reach 1.25Gbps 1310nm SFP Optical Transceiver 40KM Transmission Distance 2
