18CH Micro CWDM Aluminum Mini Box Mux Demux Singe Fiber LC UPC 1270nm 1610nm
Product Details:
| Place of Origin: | China |
| Brand Name: | Takfly/OEM |
| Certification: | CE,ROHS,REACH,ISO9001,ISO14001 |
| Model Number: | 18CH CCWDM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | USD130/pcs ~ USD230/pcs |
| Packaging Details: | spone + box + carton |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, Paypal, L/C |
| Supply Ability: | T/T, Western Union, MoneyGram, Paypal, L/C |
|
Detail Information |
|||
| Channel: | 18 | Wavelength: | 1270~1610nm / 1271~1611nm |
|---|---|---|---|
| Dimension: | Aluminum Box | Connector: | LC |
| Operating Temperature: | -5~+75℃ | Storage Temperature: | -40~85℃ |
| High Light: | 1270nm Mini Box Mux Demux,18CH cwdm multiplexer,1610nm Mini Box Mux Demux |
||
Product Description
18CH Micro CWDM Mux Demux Aluminum Mini Box Singe Fiber LC/UPC 1270nm-1610nm
CCWDM Description
The CCWDM (Compact Coarse Wavelength Division Multiplexer) MUX/DEMUX is a multi-channel CWDM device with compact package designed for cost-effective multi-wavelength CWDM network applications. CCWDM is the use of the Fiber Optical Multiplexer to different wavelengths of light signals multiplexed to a single optical fiber for transmission, at the receiving end of the link, with the Fiber Optical Multiplexer fiber mixed signal is decomposed into different wavelengths signal, connected to the respective receiving device. It is based on the Thin Film Filter (TFF) technology and free-space technology platform.
CCWDM Features
CCWDM is Mini size, Wide pass band, Low Insertion Loss, High isolation, High Stability and reliability, Epoxy-free on Optical Path.
CCWDM Application
CCWDM is mainly used for WDM Network, Access Network, Cellular Application and Fiber Optical amplifier.
CCWDM Specification
| Parameter | 10 Channel | 12 Channel | 14 Channel | 16 Channel | 18 Channel | |
| Channel Wavelength(nm) | 1270~1610 / 1271~1611 | |||||
| Channel Spacing(nm) | 20 | |||||
| Passband(nm) | Channels | ±6.5 | ||||
| Isolation (dB) | Adjacent | >30 | ||||
| Non-Adjacent | >40 | |||||
| Insertion Loss(dB) | ≤1.5 | ≤1.5 | ≤1.8 | ≤1.8 | ≤2.0 | |
| Channel Ripple(dB) | <0.3 | |||||
| Fiber Type | Corning SMF-28 with 900nm loose tube | |||||
| Polarization Dependent Loss(dB) | <0.15 | |||||
| Polarization Mode Dispersion(PS) | <0.1 | |||||
| Directivity(dB) | >50 | |||||
| Return Loss (dB) | >45 | |||||
| Maximum Power Handling(mW) | 500 | |||||
| Operating Temperature(℃) | -5~+75 | |||||
| Storage Temperature(℃) | -40~85 | |||||
| Package dimension(mm) | L55*W35*H8 | L55*W45*H8 | ||||
Order Information
| CCWDM | Channel No. | Channel | Pigtail Type | Fiber length | Connector | Package dimension (mm) |
|
M=Mux |
04=4 Channel |
27=1270nm |
0=250um |
1=1m 2=1.5m 3=others |
0=None |
P1: L44 x W25 x H6 |
FAQ:
Q1: Are your a trading company or manufacturer ?
A: We are a manufacturer for more than 10 years.
Q2: Do you provide OEM service ?
A: Yes, we can print your logo or label on the products or on the box.
Q3: Can you provide free samples ?
A: Some of low value samples can be free for you, but you need pay for the shipping cost.
Q4: How can you guarentee the quality ?
A: Build on our perfect quality management system, all of our products were 100% tested before the shipment.
Q5: What is your delivery time ?
A: Generally, sample: 3~5 working days. Formal order: 7-10 working days.
Q6: What's your payment terms ?
A: We accept T/T, Western Union, Paypal, L/C
For samples: 100% payment. Formal order: 30%~100% as deposit, balance payment before shipment.
