ST-ST Fiber Optic Patch Cord with LSZH Sheath for Low Insertion Loss and Custom Length Data Center Use
Product Details:
| Place of Origin: | China |
| Brand Name: | DF/OEM/Nuetral |
| Certification: | CE/ROHS/REACH/ISO9001/ISO14001 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100PCS |
|---|---|
| Price: | US$0.01~2.79/PC |
| Packaging Details: | Export Standard Packing |
| Delivery Time: | 3-9 working days depends on QTY |
| Payment Terms: | Western Union,T/T,MoneyGram/Paypal |
| Supply Ability: | 10000PCS/Day |
|
Detail Information |
|||
| Highlight: | LSZH Sheath Fiber Optic Patch Cord,Low Insertion Loss Fiber Optic Patchcord,Custom Length Fiber Optic Jumper |
||
|---|---|---|---|
Product Description
Product Overview
ST-ST Duplex/Simplex Patch Cord
High-Performance Fiber Optic Patch Cords: Reliable Connectivity, Wide Applicability, Assured Quality
This series of fiber optic patch cords provides high-performance and highly reliable connectivity solutions for data centers, telecommunication networks, and various demanding application environments. The products are manufactured in strict compliance with the Telcordia GR-326-CORE standard, ensuring excellent mechanical properties and optical stability.
Core Applications of Fiber Optic Patch Cord
- CATV
- Telecommunication networks
- Active device termination
- Local area networks (LANS)
- Data processing networks
- Test equipment
- Wide area networks (WANS)
Features of Fiber Optic Patch Cord
- Excellent Optical Performance: Low insertion loss and high return loss ensure efficient and clean signal transmission.
- Outstanding Interchangeability and Durability: Stable plug-and-play performance with minimal degradation from repeated use, suitable for environments requiring frequent operation.
- High Environmental Adaptability: Good high-temperature stability, with an operating temperature range from -20℃ to 70℃.
- Optional Safety Materials: The outer sheath is available in PVC, LSZH (Low Smoke Zero Halogen), and TPU materials to meet flame-retardant and safety requirements for different installation environments.
Specifications of Fiber Optic Patch Cord
| End face type | UPC and APC |
|---|---|
| Fiber type | SM(G652, G655, G657); MM(OM1-OM5) |
| Cable Diameter | 2.0, 3.0 or customized (Simplex/duplex) |
| Insertion loss | ≤ 0.3dB |
| Return loss | UPC SM ≥50dB, APC SM ≥ 60dB, UPC MM ≥ 35dB |
| Repeatability | ≤ 0.1 |
| Durability | ≤ 0.2dB |
| Interchangeability | ≤ 0.2dB |
| Tensile strength | >70N |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -40℃~80℃ |
| Outer Sheath Material | PVC, LSZH, TPU |
| Bending radius (Static/Dynamic) | 10D/20D |
| Length | Customized |
How to Order Fiber Optic Patchcord
- Connector type: SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
- Mode type: single mode (UPC and APC) / multi mode (PC)
- Cable diameter: 0.9 / 2.0 / 3.0 mm (can customize other diameters)
- Coating material: PVC / LSZH
- Fiber count: simplex / duplex / 4 core / 6 core / 8 core / 12 core / 24 core / 48 core / 96 core and more
- Cable type: G652D / G657A1 / G657A2 / G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 / OM5
- Patch cord length: according to your requirement
Why Choose TAKFLY?
Core Advantages
- Founded in 2000, Located in Shenzhen (south of China neighbor Hongkong)
- FTTH, DATA Center Solution, One-stop fiber optic components supply
- ISO 9001/14001/RoHS/CE/FCC certified quality
- Factory-direct pricing & strict quality control
- Customized production & on-time delivery
- 25 years' expertise + 30 engineers' R&D support
- Accept trial/small orders
- Main customer: Vodafone, Orange, Telefornica, Movistar, Ericsson, etc.
- Worldwide exhibitions: OFC, CommunicAsia, ECOC, Netcom, Cable Tech, Network X, SVIAZ ICT, AFRICACOM, CAIRO ICT, etc.
Premium Services
- 3-7 days for samples; 2-3 weeks for bulk (urgent orders supported)
- 100% pre-shipment testing
- Prompt response & full after-sales support
