Industrial POE Switch 5-Port Gigabit DIN-Rail Mount IP40
Product Details:
| Place of Origin: | China |
| Brand Name: | TAKFLY/OEM |
| Certification: | CE, ROHS, REACH |
| Model Number: | DF-1G-4GPI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 23.14USD |
| Packaging Details: | Carton box |
| Delivery Time: | 2~3 days |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 5000 piece/week |
|
Detail Information |
|||
| Interface: | 4x10/100/1000Base-T POE Port + 1 Port 1000Base Ethernet Uplink | Power Supply: | Input Voltage: DC48～57V/Terminal Block |
|---|---|---|---|
| Shell: | IP40 Protect Grade, Metal Shell | Installation: | DIN-Rail Or Wall Mount |
| Weight: | 0.36kg | Size: | 128x86x34mm |
| Warranty: | 5-years | ||
| Highlight: | 5-port industrial POE switch,Gigabit DIN-rail Ethernet switch,IP40 rated industrial network switch |
||
Product Description
Outdoor Industrial POE Ethernet Switch
5×10/100/1000M Gigabit Industrial Best POE Ethernet Switch
Product Attributes
| Attribute | Value |
|---|---|
| Interface | 4x10/100/1000Base-T POE port + 1 port 1000Base Ethernet Uplink |
| Power Supply | Input Voltage: DC48～57V/Terminal block |
| Shell | IP40 protect grade, metal shell |
| Installation | DIN-Rail or wall mount |
| Weight | 0.36kg |
| Size | 128x86x34mm |
| Warranty | 5-years |
Product Description
Industrial PoE switch with 4 Port 10/100/1000Mbps PoE ports + 1 port Ethernet uplink, for connecting with devices like computers, switches, hubs, servers, etc., as well as powering network cameras, industrial VoIP phones, wireless APs and other PoE supported devices.
Specially designed for harsh outdoor applications. Its 6KV network port surge protection can adapt to harsh outdoor environments and ensure the reliability of the uninterrupted PoE system. Power input also chooses industry-standard types of power.
Features
- 5 Port 10/100/1000Mbps
- 1-4 Port support PoE, supports IEEE 802.3af(15.4W), IEEE802.3at PoE (30W)
- Automatic MAC address learning and aging
- Automatically support IGMP (Multicasting)
- 10/100/1000Mbps Auto-negotiation, auto-MDI-MDI-X
- LED indicators for monitoring power/link/activity
- Supports 10/100/1000Mbps-Full/Half-duplex
- Supports DIN-Rail and Wall mount installation
- -40℃~+85℃ operating temperature range
- 5-Year Warranty
Specifications
| Interface | 4x10/100/1000Base-T POE port + 1 port 1000Base Ethernet Uplink | Network Protocols | IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u; 100Base-TX/FX; IEEE802.3ab 1000Base-T; IEEE802.3z; IEEE802.3x; IEEE802.3af, IEEE802.3at |
|---|---|---|---|
| PoE Specification | PoE Standard: IEEE802.3af/ IEEE802.3at PoE ports: 1~4 port support PoE Output Voltage: DC48V |
Network Media | 10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or later UTP(≤100 meter) 1000BASE-TX: Cat6 or later UTP(≤100 meter) |
| LED Indicators | Power: PWR; Link; PoE; Link/Act | Power Supply | Input Voltage: DC48～57V /Terminal block |
| Installation | DIN-Rail or Wall mount | Warranty | 5 years |
