Industrial Gigabit POE Switch with 1 SFP Port and DIN-Rail Mounting
Product Details:
| Place of Origin: | China |
| Brand Name: | TAKFLY/OEM |
| Certification: | CE, ROHS, REACH |
| Model Number: | DF-1FG-1GPI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 24.00USD |
| Packaging Details: | Carton box |
| Delivery Time: | 2~3 days |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 5000 piece/week |
|
Detail Information |
|||
| Interface: | 1x 10/100/1000Base-T POE Port + 1x 1000Mbps SFP Slot | Power Supply: | Input Voltage: DC48～57V (PoE) /Terminal Block; DC12～48V(Converter)/Terminal Block |
|---|---|---|---|
| Shell: | IP40 Protect Grade, Metal Shell | Installation: | DIN-Rail Or Wall Mounting |
| Weight: | 0.36kg | Size: | 12.5×10.4cm×3.4cm |
| Warranty: | 5-years | ||
| Highlight: | Industrial Gigabit POE Switch,Gigabit POE Switch with SFP,DIN-Rail Mount POE Switch |
||
Product Description
POE Ethernet switch 1 SFP port media converter 10/100/1000M gigabit industrial best POE Ethernet switch
Product Attributes
| Attribute | Value |
|---|---|
| Interface | 1x 10/100/1000Base-T POE port + 1x 1000Mbps SFP slot |
| Power Supply | Input Voltage: DC48～57V (PoE) /Terminal block; DC12～48V(Converter)/Terminal block |
| Shell | IP40 protect grade, metal shell |
| Installation | DIN-Rail or Wall mounting |
| Weight | 0.36kg |
| Size | 12.5×10.4cm×3.4cm |
| Warranty | 5-years |
Product Description
Industrial PoE switch including 1 port 1000Mbps SFP slot and 1 port 10/100/1000Mbps PoE ports, for connecting with devices like computer, switch, hub, server, etc. as well as powering network camera, wireless AP and other PoE supported devices.
Specially designed for harsh outdoor applications. Its 6KV network port surge protection can adapt to harsh outdoor environment and ensure the reliability of the uninterrupted PoE system. Power input also chooses industry-standard types of power.
Features
- 1 port support PoE, supports IEEE 802.3af(15.4W), IEEE802.3at PoE(30W)
- Automatic MAC address learning and aging
- Automatically support IGMP(multicasting)
- Supports 10/100/1000Mbps-Full/Half-duplex
- Supports Broadcast Storm Control
- Supports Daisy-Chain connection
- Redundant dual DC power inputs
- Harsh industrial environment or higher requirement
Specifications
| Interface | 1x 10/100/1000Base-T POE port + 1x 1000Mbps SFP slot |
|---|---|
| Network Protocols | IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;IEEE802.3u;100Base-TX/FX; IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x; IEEE802.3af, IEEE802.3at |
| PoE Specification | PoE Standard: IEEE802.3af/ IEEE802.3at |
| Network Media |
10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or later UTP(≤100 meter) 1000BASE-TX: Cat6 or later UTP(≤100 meter) |
| Fiber Media | Multi-mode: 2KM; Single-mode: 20/40/60/80KM |
| Power Supply |
Input Voltage: DC48～57V (PoE) /Terminal block DC12～48V (Converter) /Terminal block |
| Installation | DIN-Rail or Wall mounting |
| Warranty | 5 years |
