Product Details:

Place of Origin: China,Shenzhen
Brand Name: OEM/Takfly
Certification: CE, ROHS, REACH, ISO9001, ISO14001
Model Number: MPO/MTP-FTTH

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Can be negotiated
Packaging Details: Carton
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union
Supply Ability: 50000pcs per month
Get Best Price Contact Now

Detail Information

Material: LSZH, PVC... Customizable: Available
Color: Negotiated Type: Multi-mode Fiber
Operating Temperature: -10 To 60°C (14 To 140°F) Storage Temperature: -10 To 70°C (14 To 158°F)
Highlight:

FTTH Patch Cord Trunk Cable

,

Panel MPO Fiber Cable

,

Optical Fiber FTTH Patch Cord

Product Description







Basic Info.



Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 0

Product description



The MT-RJ and MPO are the MT series. Small size, Multi-channel is the most prominent feature, which greatly facilitates the high-density wiring. The MT series connectors have been widely applied to theCATV, Multimedia, Gigabit Ethernet, active device interface, data processing networks, telecommunication networks, asynchronous Transmission Mode (ATM). The MT-RJ is duplex ferrule plug-jack (RJ-45) design and the MPO can be 24 fibers, the MPO patchcord cable can be ribbon fiber or breakout fiber, also, the MTP is available; the MT series patchcord have low insertion loss and high precision guide pins exact alignmen.

Specifications

Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 1





Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 2





MTP/MPO Type-B Cable Applications

Due to the special construction of MPO/MTP type-B cable, a female connector MPO/MTP cable is usually needed to match the male connector MPO/MTP cable. The male guide pin fits into the female bore to ensure precise fiber alignment. Attempting to mate two female or male connectors can result in light loss or damage to the fiber splice. The following examples focus on the application of female MPO/MTP type-B cables.

40G-40G Direct Connetction: Female to Female MTP/MPO Type-B Polarity Trunk Cable

Expect for the parallel 40G optical transmission mentioned above, female to female type-B trunk cable also can be used for direct switch to switch connetcivity with no patch panels. The following figure shows Cisco 40G switches connected by a 12-fiber MPO/MTO female cable directly.





Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 3

Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 4

Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 5

Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 6

Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 7

Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 8

Optical Fiber FTTH Patch Cord Trunk Cable PVC Material Panel MPO Fiber Cable 9
