MPO - 8xLC Fiber Patch Cord Multimode OM5 8F 3.0mm LSZH MPO Fiber Cable
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | Neutral/OEM |
| Certification: | CE/ROHS/REACH/CPR/ISO9001/ISO14001 |
| Model Number: | OM5 MPO-LC Patch Cord |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Zip-lock Bag |
| Delivery Time: | 3-5 working days |
| Payment Terms: | Western Union, L/C, T/T, Paypal |
| Supply Ability: | 100PCS/Day |
|
Detail Information |
|||
| Cores: | 8 Cores | Fiber Type: | MM OM5 |
|---|---|---|---|
| Connector A: | MPO/PC | Connector B: | LC/PC |
| Cable Diameter: | 3.0mm Round | Cable Color: | Lime Green LSZH Round |
| High Light: | MPO - 8xLC Fiber Patch Cord,Multimode Fiber Patch Cord,3.0mm MPO Fiber Cable |
||
Product Description
Fiber Patch Cord MPO-8xLC Multimode OM5 8F 3.0mm LSZH MPO Fiber Cable
Fiber Optic MPO-8xLC OM5 Patch Cord Name:
MPO-LC Multimode OM5 Lime Green 8F Patch Cord Standard Loss
Fiber Optic MPO-8xLC OM5 Patch Cord Description:
This Patch Cord MPO-LC Multimode OM5 of 8F Patch Cord is in Lime Green.
Other cores like 12 cores, 24 cores are also available.
Fiber Optic MPO-8xLC OM5 Patch Cord Features:
| Precision molded MT ferrule |
| High precision guide pins for exact alignment |
| Compact design, up to 4,8,12,24 fibers |
| IEC 61754-7 Compliant |
| Cable diameter 3.0mm |
Fiber Optic MPO-8xLC OM5 Patch Cord Applications:
- Telecommunication Networks
- Active Deviced/Transceiver Interface
- Gigabit Ethernet
- CATV, Video and Multimedia
- Premise Installations
- Optical Switch interframe connections
- Data Center
Fiber Optic MPO-8xLC OM5 Patch Cord Specifications:
| Item | MPO/MTP | LC | |
| End face type | PC | PC | |
| Fiber type | SM(G652,G655,G657)；MM(OM1-OM5) | ||
| Core number | 8 | ||
| Cable Diameter | 0.9,2.0,3.0 | Mini Round cable:Max4.5mm； Ribbon cable:Max3.0*5.0mm | |
| Insertion loss(dB) | ≤ 0.3 | Standard:≤0.35/0.7(Typical/Max) Low Loss:≤0.2/0.35(Typical/Max) | |
| Return loss(Min) |
UPC SM:40dB APC SM:60 dB PC MM:25 dB |
SM: APC:60dB | MM: PC:20dB |
| Test Wavelength (nm) | SM:1310/1550 MM:850/1300 | ||
| Repeatability | ≤ 0.1dB | ||
| Durability | ≤ 0.2dB | ||
| Interchangeability | ≤ 0.2dB | ||
Why choose TAKFLY--Advantages as follows:
Professional manufacturer:
- With more than 20 years manufacturing experience in Fiber optic products;
- More than 250 assembly workers with 3 years experienced;
- More than 10 R&D Engineers;
- 16 Sets Germany imported Injection Machine and 16 Production Lines;
- More than 30 sets of Testing Machines: OTDR,3D,VFL,IL&RL test instrument; tension strenth tester, Crush Resistance tester, Power meter tester, light checker, ect.
- OEM Brand is acceptable.
- Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia ,Global Soure Electronic Exhibition,etc.
Quality Control:
- Spot check the raw material incoming inspection before production;
- Fully check after every individual process finished;
- Fully check production half done;
- Fully check the finished products before packing;
- Spot check before shipping;
Delivery:
- Samples: 1-3 working days.
- Mass Production Order: 3-7 working days.
- Packaging: Plastic Bag, Carton and Pallet are available according to your request.
Shipping:
- * DHL,UPS,FEDEX,TNT,EMS, usually is 3-5 working days. Would keep tracking shipping status and reporting to clients;
- * By Sea or By Air, could use your own pointed forwarder or our cooperated one.
Payment Term: T/T,Paypal, Western Union and L/C are available.
Price: If your QTY is big, the price could be negotiated.
