GYTA53 Outdoor Fiber Optic Cable SM G652D For Duct And Direct Buried
Product Details:
| Place of Origin: | China |
| Brand Name: | OEM/Takfly |
| Certification: | CE,ROHS,REACH,ISO9001,ISO14001 |
| Model Number: | GYTA53 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2KM |
|---|---|
| Price: | USD300/KM ~ USD1000/KM |
| Packaging Details: | 2-4km per Wooden Drum |
| Delivery Time: | 7-11 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, Paypal, L/C |
| Supply Ability: | 2000km channels each month |
|
Detail Information |
|||
| Product Name: | 12 To 144 Cores GYTA53 Outdoor Fiber Optic Cable | Outer Sheath Material: | HDPE , MDPE |
|---|---|---|---|
| Armored: | Steel | Loose Tube: | PBT/PP |
| Strength Member: | Steel Wire Or Steel Wire With PE Cover | Thickness Of Outer Sheath: | 1.7mm |
| Fiber Type: | SM G652D , G657A , G657B | Short Term Tensile Strength: | 3000N |
| Long Term Tensile Strength: | 1000N | Length Per Drum: | 2KM Or Customized |
| High Light: | GYTA53 Outdoor Fiber Optic Cable,SM G652D Duct Fiber Optic Cable,Direct Buried Adss Fiber Cable |
||
Product Description
12 to 144 Cores GYTA53 Outdoor Fiber Optic Cable , SM G652D, For Duct and Direct buried
GYTA53 Outdoor Fiber Optic Cable Description:
GYTA53 Outdoor Fiber Optic Cable is widely used in Aerial, Duct, Direct buried Outdoor Application, because it's double armored structure.
GYTA53 uses metal strength member as central strength member to provide excellent strain performance of the cable. Double jacket structure provide the cable nice properties of moisture resistance and crush resistance.
Double armored structure provides cable good property of rodent-resistance. A layer of water-blocking material is appliedaroundthe cable core to prevent water ingress. It can be used for duct and direct buried application.
S
GYTA53 Outdoor Fiber Optic Cable Characteristic
- Good mechanical and temperature performance
- High strength loose tube that is hydrolysis resistant
- Special tube filling compound ensure a critical protection of fiber
- Crush resistance and flexibility
- The following measures are taken to ensure the cable watertight:
- Steel wire used as the central strength member
- Loose tube filling compound
- 100% cable core filling
- APL moisture barrier
- PSP enhancing moisture-proof
- Water-blocking material
GYTA53 Outdoor Fiber Optic Cable Application:
- Adopted to outdoor distribution;
- Suitable for aerial, duct and direct buried;
- Long distance and local area network communication.
Fiber Charateristic:
| G.652.D | G.655 | 50/125μm | 62.5/125μm | ||
| Attenuation | @850nm | ≤3.5 dB/km | ≤3.5 dB/km | ||
| @1300nm | ≤1.5 dB/km | ≤1.5 dB/km | |||
| @1310nm | ≤0.36 dB/km | ≤0.40 dB/km | |||
| @1550nm | ≤0.22 dB/km | ≤0.23dB/km | |||
| Bandwidth | @850nm | ≥500 MHz·km | ≥200 MHz·km | ||
| @1300nm | ≥1000 MHz·km | ≥600 MHz·km | |||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
| Cable Cut-off Wavelengthλcc | ≤1260nm | ≤1480nm | |||
GYTA53 Outdoor Fiber Optic Cable Technical Data:
| Item | Contents | Value |
| Loose tube | material | PBT/PP |
| diameter | Ф2.0mm | |
| Central strength member | material | Steel wire/Steel wire with PE cover |
| diameter | Ф1.4~2.0mm | |
| Inner sheath | material | MDPE/HDPE |
| Thickness | 1.0mm | |
| Outer sheath | material | MDPE/HDPE |
| Thickness | 1.7mm |
GYTA53 Outdoor Fiber Optic Cable Mechanical characteristic:
| Cable type |
Diameter (mm) |
Weight (Kg/km) |
Max.Tension (N) |
Crush Resistance (N/100mm) |
Min. Bending Radius (mm) |
Storage temperature (℃) |
|
| Long/Short Term | Long/Short Term | Dynamic | Static | ||||
| GYTA53-2~60 | 12.5 | 160 | 600/1500 | 1000/3000 | 20D | 10D | -20~+70 |
| GYTA53-62~72 | 14.5 | 210 | 1000/3000 | ||||
| GYTA53-74~96 | 15.7 | 245 | |||||
| GYTA53-122~144 | 18.5 | 320 | |||||
