512C 1U 256F Fiber Optic Patch Panel MPO CS FTTH Patch Panel
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | Neutral/OEM/Takfly |
| Certification: | CE/ROHS/REACH/CPR/ISO9001/ISO14001 |
| Model Number: | MPO-CS Patch Panel |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | PE bag |
| Delivery Time: | 3-7working days |
| Payment Terms: | Western Union, L/C, T/T, Paypal |
| Supply Ability: | 100PCS/Day |
|
Detail Information |
|||
| Cores: | 256 Cores, Max. 512 Cores | Fiber Type: | SM; MM |
|---|---|---|---|
| Length: | Customized Available | Cable Diameter: | 0.9mm; 3.0mm |
| Connector Type: | CS, MPO, MTP, LC | Cable Jacket: | LSZH, And Others |
| Cable Color: | Yellow, Or Customize | Application: | Data Center, Telecom, Networks, FTTH |
| Product Name: | Fiber Optic MP-CS Patch Panel | Other Fanout Way: | Available To Choose |
| High Light: | 1U 256F Fiber Optic Patch Panel,512C Fiber Optic Patch Panel,MPO CS FTTH Patch Panel |
||
Product Description
1U 128F MPO-CS Connector Rack Mount Fiber Optic Patch Panel
Fiber Optic MPO-CS Patch Panel Name:
1U 19 Inch 128F MPO-CS Patch Panel
Fiber Optic MPO-CS Patch Panel Description:
1U 256 Cores, and 2U for max 512 Cores MPO-CS Fiber Optic Patch Panel.
This type MPO-CS Patch Panel is designed to manage and house easy-plug MTP / MPO to LC fiber cassette modules, for connecting plug-and-play pre-terminated high density MTP / MPO Fiber cabling system.
Each MPO-CS cassette can hold 64 cores, 1U panel with 4 cassettes by 256 cores; while for 2U can reach max 512 cores. Another advantage is with small size, which is 40% size lesnn than the common LC connector, and it can save 30% panel space than LC Duplex connector.
Fiber Optic MPO-CS Patch Panel Features:
| Up to 4 Small MPO-CS modules in 1U; Max for 512 Cores for 2U |
| 40% size less than common LC connector |
| 1.25mm Ferrule applicated |
| Save 30% Panel space than LC duplex |
| Connector with pull bar, easy to use |
| Multiple adaptor options available |
| Accepts loose tube, distribution and pre-terminated cables |
| ROHS, REACH SvHC and UL rated |
| Fits standard 19 inch size |
Fiber Optic MPO-CS Patch Panel Applications:
- Telecommunication Networks
- Data Center
Fiber Optic MPO-CS Patch Panel Specifications:
| Size | 1U (44mm); 2U |
| Number of Ports | 4; 8 |
| Width | 482mm |
| Depth | 380mm |
| Net Weigh | 3kgs |
| Packaged Weight | 3.5kgs |
| Material | 1.2mm Cold-rolled steel |
| Material Coating | Powder coating |
| Color | Black |
| Designed in Accordance With | TIA/EIA 568.C, ISO/IEC 11801, EN50173, IEC60304, IEC61754,EN297-1 |
| Compliant to | RoHS, Reach/SVHC |
Why choose TAKFLY--Advantages as follows:
Professional manufacturer:
- With more than 21 years manufacturing experience in Fiber optic products;
- More than 450 assembly workers with 3 years experienced;
- More than 10 R&D Engineers;
- 16 Sets Germany imported Injection Machine and 16 Production Lines;
- More than 30 sets of Testing Machines: OTDR,3D,VFL,IL&RL test instrument; tension strenth tester, Crush Resistance tester, Power meter tester, light checker, ect.
- OEM Brand is acceptable.
- Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia ,Global Soure Electronic Exhibition,etc.
Quality Control:
- Spot check the raw material incoming inspection before production;
- Fully check after every individual process finished;
- Fully check production half done;
- Fully check the finished products before packing;
- Spot check before shipping;
Delivery:
- Samples: 1-3 working days.
- Mass Production Order: 3-7 working days.
- Packaging: Plastic Bag, Carton and Pallet are available according to your request.
Price: If your QTY is big, the price could be negotiated.
