8/12/24 Cores MPO/MTP Female to LC Fiber Optic Fanout Cable , OM3 50/125 For QSFP

8/12/24 Cores MPO/MTP Female to LC Fiber Optic Fanout Cable , OM3 50/125 For QSFP

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Neutral/OEM/Takfly
Certification: CE/ROHS/REACH/CPR/ISO9001/ISO14001
Model Number: TK-PC-MPO-LC-12F-OM3

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: US$13.99~US$29.99/PC
Packaging Details: PE bag
Delivery Time: 3-7working days
Payment Terms: Western Union, L/C, T/T,Paypal
Supply Ability: 500PCS/Day
Get Best Price Contact Now

Detail Information

Cores: 8/12/24 Fiber Type: OM3
Length: 3/10/20M Or Customized Cable Diameter: 3.0mm
Connector Type: MPO/MTP, Female , UPC Insertion Loss: Standard: 0.6dB, Low Loss: 0.3dB
Return Loss: MM PC: 20dB Cable Jacket: LSZH
Cable Color: Aqua Application: Data Center, Telecom, Network
Certification: CE, ROHS, REACH, CPR, ISO9001, ISO14001 Product Name: 8/12/24 Cores MPO/MTP Female To LC UPC Fiber Optic Fanout Cable

Product Description

8/12/24 Cores MPO/MTP Female to LC Fiber Optic Fanout Cable , OM3 50/125 For QSFP



MPO MTP Female To LC fanout/breakout cables are the ideal connection to patch panels and data distribution routing. They can be made with both 12 fiber MTP connectors and 24 Fiber MTP connectors. A variety of options are available and include MPO/MTP to LC, SC, ST, and FC fiber optic patch cables.



MPO/MTP has a polarity distinction. In order to ensure the accuracy of the polarity in the MTP/MPO network system, we usually need to confirm the polarity of the MTP/MPO before production. There are three types of polarity :Type A (straight type), Type B (cross), and Type C (cross pair).

8/12/24 Cores MPO/MTP Female to LC Fiber Optic Fanout Cable , OM3 50/125 For QSFP 0

8/12/24 Cores MPO/MTP Female to LC Fiber Optic Fanout Cable , OM3 50/125 For QSFP 1







Certiticates for MPO MTP Female To LC Fiber Optic Fanout Cable : Takfly has been certified with CE, ROHS, REACH , CPR, ISO9001 and ISO14001.



MPO / MTP Fiber Optic Trunk Cable Specifications:



Item LC / SC / ST / FC....... MPO / MTP
End face type PC / UPC / APC PC and APC
Fiber type SM(G652 / G655 / G657);MM(OM1-OM5)
Core number 2 / 4 / 6 / 8 / 12 / 24
Cable Diameter 0.9 / 2.0 / 3.0

Mini Round cable:Max4.5mm;

Ribbon cable:Max3.0*5.0mm

Insertion loss(dB) ≤ 0.3

Standard:≤0.35/0.7(Typical/Max)

Low Loss:≤0.2/0.35(Typical/Max)

Return loss(Min)

UPC SM:40dB

APC SM:60 dB

PC MM:25 dB

SM:

APC:60dB

MM:

PC:20dB

Test Wavelength(nm)

SM:1310/1550

MM:850/1300

Repeatability ≤ 0.1dB
Durability ≤ 0.2dB
Interchangeability ≤ 0.2dB
Operating Temperature -20℃~70℃
Storage Temperature -40℃~80℃
Outer Sheath Material PVC / LSZH
Bending radius(Static/Dynamic) 10D/20D
Length Customized



MPO MTP Female To LC Fiber Optic Fanout Cable Features:

  • Precision molded MT ferrule
  • High precision guide pins for exact alignment
  • Compact design, up to 4,8,12,24 fibers
  • EC 61754-7 Compliant
  • EIA/TIA-604-5 Compliant

MPO MTP Fiber Optic Fanout Cable Applications:

  • Asynchronous Transmission Mode(ATM)
  • Gigabit Ethernet
  • Active Deviced/Transceiver Interface
  • CATV, Video and Multimedia
  • Premise Installations
  • Telecommunication Networks
  • Parallel optical interconnect between PC Cards and patch panels
  • Interconnection for O/E modules
  • Industrial & Military
  • Optical Switch interframe connections

8/12/24 Cores MPO/MTP Female to LC Fiber Optic Fanout Cable , OM3 50/125 For QSFP 2

8/12/24 Cores MPO/MTP Female to LC Fiber Optic Fanout Cable , OM3 50/125 For QSFP 3



With 21 years manufacturing experince in Fiber Optic Products, Takfly pay high attention to the production of high quality standard of MPO/MTP products, which include MPO-MPO and MTP-MTP Trunk Cable, MPO/MTP-LC, MPO/MTP-SC, MPO/MTP-FC, MPO/MTP-ST and MPO/MTP-CS breakout cable, MPO/MTP Cassette, MPO Patch Panel, ect.

The advantages of Takfly’s MPO products as below:

  • CE, ROHS, CPR, ISO9001 and ISO14001 certified.
  • High performance in insertion loss return loss.
  • Connector fibers from 2 fibers to 72 fibers.
  • OEM brand is available.
  • Competitive price and fast delivery.

 If you’re dealing with data center and 5G projects, Takfly would be your good choice.



I have been working in this field more than 6 years, I believe, I could give you very good service and professional answers!



If you’re interested in our products or have any doubt, why not send me inquiry at once?
