FTTH Field-Assembled LC/SM UPC/APC Field Installable Fiber Fast Connector For Indoor Drop Cable
Product Details:
| Place of Origin: | China, Shenzhen |
| Brand Name: | DF/OEM/Nuetral |
| Certification: | CE/ROHS/REACH/ISO9001/ISO14001 |
| Model Number: | FTTH Field-Assembled LC/SM UPC/APC Field Installable Fiber Fast Connector For Indoor Drop Cable |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiable |
|---|---|
| Price: | negotiable denpend on QTY |
| Packaging Details: | Blister box+Carton |
| Delivery Time: | 5-9 working days depends on QTY |
| Payment Terms: | Western Union,T/T,/Paypal |
| Supply Ability: | 1000PCS/Day |
|
Detail Information |
|||
| Product Name: | FTTH Field-Assembled LC/SM UPC/APC Field Installable Fiber Fast Connector For Indoor Drop Cable | Fiber Diameter: | Drop Cable 2.0*3.0mm |
|---|---|---|---|
| End Face Polished: | UPC /APC | Insertion Loss:: | Average Value≤0.25 DB,max Value≤0.4 DB Min |
| Return Loss:: | ＞45dB, Typ.＞50dB ( SM Fiber UPC Polish) | Tensile Stength:: | ＜30N (＜0.2dB With Impressed Pressure) |
| Operating Temperature: | -40°C～+85 °C | Fiber Brand: | Corning, YOFC, OFS, Draka |
| Highlight: | FTTH LC Field Connector,SM UPC APC Fast Connector,Indoor Drop Cable Connector |
||
Product Description
The FTTH Field-Assembled LC/SM UPC/APC Field Installable Fiber Fast Connector is engineered for rapid, reliable fiber terminations in the field. It enables installers to terminate and connect fibers within minutes at equipment racks and fiber patch panels, delivering high installation quality, a high success rate, and long-term reliability.
- FTTH and outdoor fiber terminal endpoints
- Harsh environment deployments
- FTTA BBU and RRU connections
- Data and video transmission
- Optical fiber access for mobile base stations
- Factory-installed fiber stub
- No epoxy or polishing required
- Quick and easy field fiber termination
- Eliminates cable excess length and pigtail splice storage
- Cost-effective solution
- Low insertion loss and back reflection loss
- Extremely easy operation
- Short operation time
| Item | LC |
|---|---|
| Length | 45mm |
| Ferrules | LC-SM/UPC / LC-SM/APC |
| Inner Diameter of Ferrules | 125um |
| Insertion Loss | AVG ≤ 0.3dB, MAX ≤ 0.5dB |
| Return Loss | UPC ≥ 45dB / APC ≥ 50dB |
| Working Temperature | -20 ~ +75℃ |
| Storage Temperature | -40 ~ +85℃ |
| Mating Times | 500 times |
| Cable Diameter | Drop cable: 2.0×1.6mm / 2.0×3.0mm / 2.0×5.0mm; Round cable: 5.0mm / 3.0mm / 2.0mm / 0.9mm (0.9mm with tail) |
LC-SM/APC (left) and LC-SM/UPC (right) connector components
- 26+ years of manufacturing experience in fiber optic products
- 450+ assembly workers with 3+ years of experience
- 10+ R&D engineers
- 16 Germany-imported injection machines and 16 production lines
- 30+ testing machines: OTDR, 3D, VFL, IL&RL test instruments, tension strength testers, crush resistance testers, power meter testers, light checkers
- OEM branding accepted
- Global exhibition participation: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia, Global Source Electronic Exhibition
- Raw material incoming inspection before production
- Full inspection after every individual process
- Comprehensive half-done production checks
- Complete finished product inspection before packing
- Pre-shipping spot checks
- Samples: 1–3 working days
- Mass production order: 3–7 working days
- Packaging: plastic bag, carton, and pallet available per request
