40G QSFP+ to 4x10G SFP+ Copper Cable DAC 40G-4*10G Copper Pigtail Passive Cable 1m to 7m
Product Details:
| Place of Origin: | China |
| Brand Name: | Takfly |
| Certification: | CE,ROHS,FCC,REACH,ISO9001,ISO14001 |
| Model Number: | TKC40GQSFP-xM |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | USD 23/pcs ~ USD 123/pcs |
| Packaging Details: | blister box + spone + carton |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T, Western Union, MoneyGram, Paypal, L/C |
| Supply Ability: | 30000pcs/month |
|
Detail Information |
|||
| Speed: | 40Gbps | Transmission Distance: | 1-7m |
|---|---|---|---|
| Compatible Switch Brand: | CISCO/HP/Huawei/H3C/Juniper/ZTE/........ | Material: | Copper |
| High Light: | 1m SFP+ Copper Cable,40G sfp+ direct attach cable,7m SFP+ Copper Cable |
||
Product Description
40G QSFP+ to 4x10G SFP+ Copper Cable DAC 40G-4*10G Copper Pigtail Passive Cable 1m to 7m
Description
The QSFP+ to 4x SFP+ Passive cable assemblies are high performance,cost effective for SFP+ and QSFP+ equipment interconnects . The Hybrid cables are compliant with SFF-8436 and SFF-8431 specifications. It is offer a low power consumption,short reach interconnect applications. The cable each lane is capable of transmitting data at rates up to 10Gb/s ,providing an aggregated rate of 40Gb/s.
Features
- Hybrid cable conforms to the Small Form
Factor SFF-8436 and SFF-8431 - Support for multi-gigabit data rates :1.0 Gbps
- 10.3125 Gbps (per channel) - Maximum aggregate data rate: 41.25 Gbps
(4 x 10.3125Gbit/s) - Hybrid cable link length up to 5m (passive limiting)
- High-Density QSFP 38-PIN and 4x SFP 20-PIN Connector
- Power Supply :+3.3V
- Low power consumption: 0.02 W (typ.)
- Temperature Range: 0~ 70 °C
Application
- 10G/40Gigabit Ethernet
- InfiniBand SDR, DDR, QDR
- Switches, Routers, and HBAs
- Data Centers
- Fibre Channel
STANDARDS COMPLIANC
QSFP+:
- SFF-8436
- QDR InfiniBand
- QSFP+ MSA
- RoHS Compliant
SFP+:
- SFF-8431
- SFP+ MSA
- RoHS Compatible
Absolute Maximum Ratings
| Parameter | Symbol | Min | Typ | Max | Units |
| Maximum Supply Voltage | Vcc | -0.5 | 4.0 | V | |
| Storage Temperature | TS | -40 | 85 | °C |
Normal operating condition
| Parameter | Symbol | Min | Typ | Max | Units | Ref. |
| Storage Ambient Temperature | -40 | +85 | °C | |||
| Operating Case Temperature | Tc | 0 | +70 | °C | ||
| Power Supply Voltage | VCC3 | 3.14 | 3.3 | 3.47 | V | |
| Power Dissipation | PD | 0.02 | W |
|
Order Information
| Part No. | Data rate | Length | AWG | Passive/Activ e | Temp |
| TKC40GQSFP-1M | Up to 40G | 1m | 30 | Passive | 0-70℃ |
| TKC40GQSFP-2M | Up to 40G | 2m | 30 | Passive | 0-70℃ |
| TKC40GQSFP-3M | Up to 40G | 3m | 30 | Passive | 0-70℃ |
| TKC40GQSFP-4M | Up to 40G | 4m | 26 | Passive | 0-70℃ |
| TKC40GQSFP-5M | Up to 40G | 5m | 26 | Passive | 0-70℃ |
Q: Do you provide OEM service ?
A: Yes, we can print your logo or label on the products or on the box.
Q: Can you provide free samples ?
A: Some of low value samples can be free for you, but you need pay for the shipping cost.
Q: How can you guarentee the quality ?
A: Build on our perfect quality management system, all of our products were 100% tested before the shipment.
Q: What is your delivery time ?
A: Generally, sample: 3~5 working days. Formal order: 7-10 working days.
Q: What's your payment terms ?
A: We accept T/T, Western Union, Paypal, L/C
For samples: 100% payment. Formal order: 30%~100% as deposit, balance payment before shipment.
