SC-LC 12f Patch Cord: Slim 12.5mm Cable, High Density
Video Overview
Get an inside view of features that deliver consistent results in daily use. This video provides a detailed walkthrough of the SC-LC 12F Patch Cord, showcasing its ultra-slim 12.5mm cable design for high-density installations. You'll see how its low insertion loss and high reliability perform in real-world applications like data centers and telecommunications networks.
Product Featured In This Video
- Features a slim 12.5mm cable diameter with a 2.0mm fiber optic sub-unit for high-density installations.
- Provides low insertion loss (≤ 0.3dB) and high return loss for superior signal integrity.
- Offers excellent durability and interchangeability with minimal performance variation.
- Maintains stable performance across a wide operating temperature range from -20℃ to 70℃.
- Complies with Telcordia GR-326-CORE standards for reliability and quality assurance.
- Available with UPC and APC end faces, compatible with single-mode and multi-mode fibers.
- Constructed with robust outer sheath materials including PVC, LSZH, and PU.
- Supports customized lengths and configurations to meet specific network requirements.
Faqs
- What are the main applications for the SC-LC 12F Patch Cord?This patch cord is designed for high-density applications in CATV, telecommunication networks, active device termination, LANs, data processing networks, test equipment, and WANs.
- What are the performance specifications for insertion loss and return loss?The patch cord ensures insertion loss ≤ 0.3dB and offers high return loss: UPC SM ≥ 50dB, APC SM ≥ 60dB, and UPC MM ≥ 35dB for reliable signal transmission.
- Can the SC-LC 12F Patch Cord be customized?Yes, it supports full customization including connector type, mode type, cable diameter, coating material, fiber count, cable type, and patch cord length to fit your specific requirements.
- What temperature ranges can this patch cord operate and be stored in?It operates effectively from -20℃ to 70℃ and can be stored in temperatures ranging from -40℃ to 80℃, ensuring performance stability in various environments.
